QINGDAO ATLAPEX INDUSTRY CO.,LTD

SPECIFICATIONS

  • Rated Load

    2000kg

  • Operating Weight

    690kg

  • Mix Lifting Height

    205mm

DESCRIPTIONS

ATLAPEX electric pallet truck adopts the most scientificand advancing design ideas. lt is second to none.Hold the firm belief that the forklift can greatly improveyour warehouse space andimprove your efficiency.

Impoted CURTiS controller

1-Ergonomic and comfortable platformfor easy operation.

The front wheels

2-It offers a supporting functionto ensure stability.

Adjustable pedal

3-With adjustable forged forks

Electromagnetic

5-Big load, flexible operation,compact structure suits forfactory & warehouse use.

Rider type pallet truck

4-Save your energy to improve the efficiency.

TECHNICAL PARAMETERS

ELECTIRC PALLET TRUCK—CBD20Ⅲ
PowerElectric
Operating TypeStanding Type
Steering ModelEPS
Load Capacity2000kg
Load Center600mm
Wheel Base1380mm
Self-weight With Battery690kg
Wheel TypePU
Front Wheelφ80*80mm
Rear Wheelφ230*75
Balance Wheelφ125*50
Max Lifting Height205mm
Fork Outer Width685/540mm
Vehicle Body Length1825/2240mm
Vehicle Boy Width760
Fork Size1150/175/55mm
Aisle Width,Pallet 1000×12002220/2620mm
Min Turning Radius1670/2070mm
Driving Speed(Unload/Load)6/5.5km/h
Lifting Speed(Unload/Load)0.043/0.04m/s
Lowering Speed(Unload/Load)0.035/0.445m/s
Max.gradeability(Unload/Load)10/8%
Service BrakeElectromagnetic
Drive Motor1.5kw
Lift Motor0.8kw
BatteryLead Acid
Battery Voltage/Nominal   Capacity24V/210Ah
Charge24V/30Ah
ChargerAC
Type Of Drive Control75dB
